Model: HX-168Q
Stamping Diameter: 45mm
Machine Speed: 1000 - 1200 cycles/hr
Machine Dimension: 550*610*1360mm
Machine Weight: 105kg
Payment Terms: T/T, L/C, Paypal
Package: Plywood
| Quantity: | |
|---|---|
HX-168Q
HX
8443.39
Technical Parameter:
| Name | Round Hot Stamping Machine |
| Model | HX-168Q |
| Stamping Plate Size | L 100 * W 168 mm |
| Worktable Size | L 108 * W 108 mm |
| Max Stamping Height | 95 mm |
| Max Stamping Diameter | 45 mm |
| Stamping Tempreature | Room ~ 280 |
| Foil Width | 100 mm |
| Stamping Head Stroke | 50 mm |
| Max Stamping Speed | 1000 pcs/hr |
| Air Consuption | 58 L/Min |
| Air Supply | 4 ~ 6 Bar |
| Power Supply | AC 110/220V 50/60HZ |
| Heating Wattage | 600W |
| Machine Dimension | L 555 * W 609 * H 1360 mm |
| Packing Dimension | L 700 * W 780 * H 1427 mm |
| Net Weight | 105.5 KG |
| Gross Weight | 130.5 KG |
Technical Parameter:
1. micro computer control system, easy to operation;
2. stamping pressure, temperature and time can be adjusted ;
3. the front / back, left / right and angle of worktable can be adjusted ;
4. automatic foils feeding and collecting system ;
5. set the stamping head height for different height products ;
6. for stamping flat products, only need to dismentle the shuttle worktable ;
7. the shuttle worktable can drive for stamping round product stablely with good quality ;
8. it's very suitable for stamping kinds of flat products, like lids, wine bottle caps, cosmetic bottle caps etc ;
