HX-GF
HX
8443.1980.00
Specifications:
1. Automatic loading and unloading.
2. PLC controls each function, touch screen operation, simple and convenient.
3. Touch screen features counter, fault alarm information.
4. Reciprocating scraper with oil bottles, ink saving, environmental effect.
5. Printing speed is adjustable to meet different printing requirements.
6. Bench can be adjusted X, or Y, Z-axis direction.
7. Printed tube position is adjustable to accommodate different lengths of printed workpiece.
8. Fuselage made of high quality aluminum alloy, light and durable.
9. Built-hydraulic buffers to reduce mechanical vibrations and reduce noise.
Technical Parameters:
Plate size | 100*250mm |
Color | single |
Ink cup diameter | 82 | 90mm for choice |
Pad vertical stroke | 75mm |
Pad angle adjust | 360 degree |
Worktable angle adjust | ±5 degree |
Suitable golf tee length | 50-90mm |
Print pressure | 1178N |
Print speed | 600 - 800 cycles/hr |
Air pressure | 5 - 7 bar |
Air consumption | 0.82Litre / Circle |
Power supply | 110/220V |
Power rate | 1500W |
Specifications:
1. Automatic loading and unloading.
2. PLC controls each function, touch screen operation, simple and convenient.
3. Touch screen features counter, fault alarm information.
4. Reciprocating scraper with oil bottles, ink saving, environmental effect.
5. Printing speed is adjustable to meet different printing requirements.
6. Bench can be adjusted X, or Y, Z-axis direction.
7. Printed tube position is adjustable to accommodate different lengths of printed workpiece.
8. Fuselage made of high quality aluminum alloy, light and durable.
9. Built-hydraulic buffers to reduce mechanical vibrations and reduce noise.
Technical Parameters:
Plate size | 100*250mm |
Color | single |
Ink cup diameter | 82 | 90mm for choice |
Pad vertical stroke | 75mm |
Pad angle adjust | 360 degree |
Worktable angle adjust | ±5 degree |
Suitable golf tee length | 50-90mm |
Print pressure | 1178N |
Print speed | 600 - 800 cycles/hr |
Air pressure | 5 - 7 bar |
Air consumption | 0.82Litre / Circle |
Power supply | 110/220V |
Power rate | 1500W |
