Model: HX-600R/4
Table Diameter: 600mm
Print Size: 200*300mm
Machine Speed: 1200 - 1500cycles/hr
Vertical Stroke: 100mm
Transverse Stroke: 400mm
Payment Terms: T/T, L/C, Paypal
Package: Plywood
| Quantity: | |
|---|---|
HX-600R/4
HX
8443.1922.90
Machine Summary:
This machine is a high speed and precise screen printer, using Taiwan Mechanical cam divider compose high speed rotary table, which have no shack when Printing, because of having more workstations, you can pick and place work piece at the same time. The speed is very quick, can be up to 1500pcs/hr. It's the first choice for you to do large quantity printing.
Features:
1. SCM IC coordinate light touching panel to compile action programming;
2. Auto 4-digit counter built-in, counting printing quantity;
3. Airframe adopts coin alloy, and metal coating surface;
4. Distyle vertical structure, high precision, steady operation;
5. The transverse stroke can be adjusted, spacing by Taiwan electronic switch;
6. The angle of scraper and ink covering blades can be adjusted randomly;
7. Installing scraper constant pressure equipment to make sure pressure is steady when printing;
8. You can regulate work-table back and forth or right and left, and then fastening it;
9. You can regulate screen frame back and forth, right and left or level orientation;
10. T-slot worktable, convenient to install mould;
11. Installing CEC oil buffer on up and down, left and right to avoid printing shocking;
12. The machine is running fast, stably and lower noise;
Technical Parameter:
| Action Model Option | Automatic | Semi-Automatic | Manual |
| Start-up Method | Padel | Panel |
| Vertical Driven | Pneumatic |
| Transverse Drive | Cylinder | Gear Motor | Servo Motor |
| Vertcial Stroke | 100mm |
| Transverse Stroke | 400mm |
| Round Worktable Diameter | 600mm |
| Print Size | 200*300mm |
| Machine Speed | 1200 - 1500 cycles/hr |
| Max Height of Product | 50mm |
| Power Supply | 220V, 50HZ |
| Air Supply | 5 ~7 Bar |
